    450 TON Trenchless Horizontal Directional Drilling Machine pipe pulling HDD machine DL4500

    Ask Lasest Price
    Brand Name : DILONG
    Model Number : DL4500
    Price : NEED DISCUSS
    Payment Terms : L/C, T/T
    Supply Ability : 30 Units PER YEAR
    Delivery Time : After advance payment in 45 days
    Certification : ISO9001
    • Product Details
    • Company Profile

    450 TON Trenchless Horizontal Directional Drilling Machine pipe pulling HDD machine DL4500

    450 TON Trenchless Horizontal directional Drilling machine pipe pulling HDD machine DL4500


    KEY POINT:

    1. Steel rubber crawler, good strength, easy installation and maintenance
    2. Multiplayer cab design, with air conditioning, vision, making the operation more comfortable
    3. Wire walking, safe and reliable
    4. Semi-automatic drill pipe brackets, simple and reliable, with 3 tons crane use, easy handling drill

    A world-class brand PALL filters ensure clean hydraulic system, making the life of the original large


    Specification:


    Enginekw559/1800Dimension(L*W*H)mm18820*3965*3500
    Max.thrust forceKN4500WeightT60
    Max.pullback forceKN4500Diameter of drill rodmmΦ140
    Max.torqueN.m120000Lendht of drill rodm9.6
    Max.Rotary speedrpm70Max diameter of pullback pipemmΦ1600
    Max.Moving speed of power headm/min30Incidence angle.9~15
    Max.mud puump flowL/minClimbing angle.~14
    Max.mud pressureMpa10±0.5Max pullback pipe lengthm~2000



    Whatsapp number: 008618936869890
